Elipta Micro Waymarker 360-12/24v DC-3w-100lm-2700K-IP67-Stainless Steel

Elipta Micro Waymarker 360-12/24v DC-3w-100lm-2700K-IP67-Stainless Steel

Product No: EP83360

37 in stock

Micro Waymarker 360
  • Elipta 20w - 12v dc - Potted LED Power Supply in Ground Burial Enclosure
    £80.40
    £67.00

    Elipta 35w - 12v dc - Potted LED Power Supply
    £57.60
    £48.00

    Elipta IP66 Junction Box c/w Terminals / Entries - 85 x 85 x 50mm - Black
    £9.00
    £7.50

    Elipta Ground Burial 2 Core Low Voltage Cable - 25m - 2.5mm²
    £69.60
    £58.00

    Elipta Cable Joint Kit
    £1.92
    £1.60

    Elipta Cable Splice Kit
    £4.32
    £3.60

    Elipta Underground Joint Kit c/w Resin Sealant Pack
    £22.80
    £19.00

    Elipta IP68 Cable Gland c/w Lock Nut - 20mm
    £0.60
    £0.50

    Elipta MPGEL Re-Enterable Clear Sealant 1 Litre Bottle
    £50.40
    £42.00

    Elipta Ground Burial 2 Core Low Voltage Cable - 25m - 1.5mm²
    £50.40
    £42.00

    Elipta 6 Way IP68 Round Junction Box c/w M16 Cable Glands
    £18.60
    £15.50

    Elipta IP68 LED Power Supply - 12v dc - 15w
    £33.60
    £28.00

    Elipta 3 Pole IP68 In-Line Cable Connector
    £12.36
    £10.30

    Elipta 3 Pole IP68 In-Line Cable Connector 'Y' Split
    £9.60
    £8.00

    Elipta 10w - 12v Dc - IP67 Potted LED Power Supply In IP65 Enclosure
    £22.80
    £19.00

    Elipta 15w - 24v Dc - IP67 Potted LED Power Supply In IP65 Enclosure
    £24.00
    £20.00

  • Product Overview
  • The Elipta Micro Waymarker (stainless steel) 360 is compatible with both 12v and 24v DC LED power supplies. 360° light output from 3 windows allows you to softly light the path or driveway and the planting bed or lawn behind. The Micro Waymarker has a glass lens that is raised to the top of the dome, preventing debris from settling and blocking the light output. The light is located by an "O" ring on the body into a sleeve tube so that external screw fixings can't be seen. It may also be used as a deck light. Purchase LED power supply separately. We recommend using a 12v constant voltage dc power supply for optimum performance.

    Colour/Finish: Smart 316 grade stainless steel is a popular choice for modern garden settings
    IP Rating: IP67
    Construction: Stainless steel top plate is attached to anodised aluminium body which push fits into the aluminium tube, where it is held firmly in place by an o-ring, leaving a front plate with no visible fixing screws. 1.5m cable via rear entry cable
    Input Voltage: 12v / 24v DC
    Wattage: 3w
    Light Output: 100lm
    Beam Angle: 360°
    Colour Temp: 2700K warm white
    Life Span: Approximately 50,000 hours
    Installation:

    The anodised aluminium sleeve is built into the floor/paving during construction or retrofitted into a hole cut with a coring bit: the light pushes into the tube, where it is held firmly in place by an o-ring, leaving a front plate with no visible fixing screws. Suitable drainage should be provided below each fitting to prevent water logging. Micro Waymarkers should not be installed in ground subject to water logging. Connect input cable to cable from an LED power supply using T9962 cable joint or T9963 cable splice kit or T9969 underground joint kit


  • More Information
  • Finish 316 stainless steel
  • Downloads
  • Reviews
