Elipta Modula Recessed Uplight - Stainless Steel - Square - 12v MR16

Elipta Modula Recessed Uplight - Stainless Steel - Square - 12v MR16

Product No: E8811N

9 in stock

Modula recessed uplights are stylish adjustable recessed uplights with a choice of 3w - 7w LED lamp.
  • Elipta 3w 260lm MR16 COB Lamp - Warm white 2700K 30°
    £15.00
    £12.50

    Elipta 6w 480lm MR16 COB LED Lamp - Warm white 2700K 60°
    £22.80
    £19.00

    Elipta 3w 260lm MR16 COB Lamp - Warm white 2700K 60°
    £15.00
    £12.50

    Elipta 7w 630lm MR16 COB Lamp - Warm white 2700K 15° Dimmable
    £22.80
    £19.00

    Elipta 7w 630lm MR16 COB Lamp - Warm white 2700K 30° Dimmable
    £14.40
    £12.00

    Elipta 7w 630lm MR16 COB Lamp - Warm White 2700K 60° Dimmable
    £22.80
    £19.00

    Elipta MR16 RGB + CCT 4w Lamp
    £22.80
    £19.00

    Elipta 5w LED Lamp - Cool White - 12v MR16 450lm 4000K 36°
    £7.20
    £6.00

    Elipta MR16 Lamp 250lm 2700K Warm White 60°
    £9.00
    £7.50

    Elipta 3.6w LED Lamp - Warm White - 12v Dimmable
    £7.20
    £6.00

  • Elipta Ground Burial Transformer - 12v ac - 50va
    £48.00
    £40.00

    Elipta 12w - 12v dc - Potted LED Power Supply in IP65 Enclosure
    £39.60
    £33.00

    Elipta 35w - 12v dc - Potted LED Power Supply in IP65 Enclosure
    £66.00
    £55.00

    Elipta Surface-Mount Exterior Transformer - 12v ac - 20va
    £30.00
    £25.00

    Elipta Surface-Mount Exterior Transformer - 12v ac - 40va
    £32.40
    £27.00

    Elipta IP65 Junction Box (Plain Sides) - 112 x 112 x 67mm - Black
    £4.80
    £4.00

    Elipta IP65 Junction Box (Plain Sides) - 160 x 120 x 71mm - Black
    £7.20
    £6.00

    Elipta IP66 Junction Box c/w Terminals / Entries - 85 x 85 x 50mm - Black
    £7.20
    £6.00

    Elipta Ground Burial 2 Core Low Voltage Cable - 50m - 2.5mm²
    £118.80
    £99.00

    Elipta Cable Joint Kit
    £1.92
    £1.60

    Elipta Cable Splice Kit
    £4.32
    £3.60

    Elipta Copper Grease Sachet 30cc
    £1.44
    £1.20

    Elipta IP68 Cable Gland c/w Lock Nut - 20mm
    £0.60
    £0.50

    Elipta MPGEL Re-Enterable Clear Sealant 1 Litre Bottle
    £50.40
    £42.00

    Elipta Ground Burial 2 Core Low Voltage Cable - 25m - 1.5mm²
    £42.00
    £35.00

    Elipta 6 Way IP68 Round Junction Box c/w M16 Cable Glands
    £18.60
    £15.50

    Elipta IP68 LED Power Supply - 12v dc - 15w
    £33.60
    £28.00

  • Product Overview
  • The stylish Elipta Modula Recessed Uplight (stainless steel) 12v will take a choice of 3w to 8w MR16 low energy LED lamps, resulting in a low lens temperature, which is important in walkover areas. The adjustable lampholder assembly can be raised or lowered within the lamp housing and tilted up to 30° which is useful for uplighting columns and statues.

    This garden light is fitted with a flush clear lens as standard, whilst the light is located by two silicone "O" rings on the body into a polycarbonate recessed sleeve tube. To facilitate the removal of screws for future relamping or other maintenance, apply copper grease to the threads of all screws being fitted for retention of bezels, grills or other top plates or retaining rings. Copper grease resists degradation due to heat and protects against difficulty in removing screws, particularly where stainless steel screws are fitted with aluminium parts. It may also be used on screw threads of screw-off bezels or glare shields. Ensure surplus is cleaned off with a solvent to prevent staining in use.

    Colour/Finish: Stainless Steel finish blends well with modern materials and timber
    IP Rating: IP67
    Construction: Front bezel is attached to tubular aluminium body. 2m cable via rear entry cable gland
    Input Voltage: 12v
    Lamp Type: 3w - 7w MR16 L.E.D. lamps include white or warm white;
    Installation: The plastic sleeve is built into the wall during construction or retrofitted into a hole cut with a coring bit: the light pushes into the tube, where it is held firmly in place by an o-ring. Connect input cable to cable from transformer using T9962 cable joint or T9963 cable splice kit.
    Accessories:

    Clip-on Lenses

    Clip-on MR16 Colour Filters

    Modula Frosted Lens

    Clip-on Honeycomb Louvre (Black)
